| One-way and two-way feeding and discharging safety grating ·Cross-check the feeding and discharging mode ·Two-way detection feeding and discharging mode ·Protection height from 800-1500MM ·Maximum protection distance is 6M-12M. ·Integrated a variety of intelligent functions ·Integrated manual or automatic reset ·External relay feedback input (EDM) |
| ▊ | Product selection |
product name | product category | height | Detection direction |
| Two-way feeding and discharging detection safety light curtain | LS4A-20-0800 | 800mm | One-way bidirectional |
Two-way feeding and discharging detection safety light curtain | LS4A-20-0900 | 900mm | One-way bidirectional |
Two-way feeding and discharging detection safety light curtain | LS4A-20-1000 | 1000mm | One-way bidirectional |
Two-way feeding and discharging detection safety light curtain | LS4A-20-1200 | 1200mm | One-way bidirectional |
Two-way feeding and discharging detection safety light curtain | LS4A-20-1500 | 1500mm | One-way bidirectional |
explain | |||
| ▊ | 2Safety combination of point-crossing feeding and discharging detection |
| Safety light curtain for cross feeding and discharging detection ·Why do you need Muting? It can prevent people from entering the dangerous operation area of the machine through the cargo opening, thus causing mechanical injury, and the cargo can pass smoothly without stopping, that is, it will not affect the production efficiency. ·Reference standards IEC 62046, ISO13849 and IEC61496.. Product composition： ·2Group sensor (cross sides) ·Safety light curtain (installed vertically in the middle) ·By sequentially detect that entrance and exit of pallet materials or AGV trolley Please download the corresponding program matching Muting program. |
| ▊ | 4Safety combination of point bidirectional parallel feeding and discharging detection |
| Two-way parallel feeding and discharging detection safety light curtain ·Why do you need Muting? It can prevent people from entering the dangerous operation area of the machine through the cargo opening, thus causing mechanical injury, and the cargo can pass smoothly without stopping, that is, it will not affect the production efficiency. ·Reference standards IEC 62046, ISO13849 and IEC61496. Product composition： ·4Group sensor (horizontal sides) ·Safety light curtain (installed vertically in the middle) ·By sequentially detect that entrance and exit of pallet materials or AGV trolley Please download the corresponding program matching Muting program. |
| ▊ | Product components |
· Safety grating (the height of the main grating is confirmed according to the site) · 2Group detection sensor (cross-mounted) is installed at the lower part of aluminum material to prevent collision. · TT-shaped fixing bracket · 5M cable |
| ▊ | Industrial application |
· Automated production line · Palletizer industry · Food packaging line industry · Warehousing industry · AGV inlet and outlet |
| ▊ | Wiring instructions |
MutingSchematic diagram of wiring, (schematic diagram of bidirectional parallel feeding and discharging detection) |
 |
| ▊ | technical parameter |
executive standard | GB/T 19436.1;GB/T 19436.2;GB 4583-2007;IEC 61496-1; IEC 61496-2 | ||
Security category | |||
security level/phase | Type 4 Cat.4 ple | ||
DCavg | 99% | ||
CCF | 100 | ||
MTTFD/PFHD | (See specification table of KS06G safety grating) | ||
Optical characteristics | |||
Detection light source | Infrared LED (center wavelength 940mm) | ||
Detection height | Optical axis spacing x (number of beams -1) | ||
EAA | Meet the requirements of IEC61496-2. When the detection distance is more than 3m, EAA is less than 2.5. | ||
Environmental characteristics | |||
ambient temperature | work | -10℃~55℃(No frost and fog) | |
store | -40℃~70℃ | ||
ambient humidity | work | 36%RH~85%RH | |
store | 36%RH~95%RH | ||
Anti-light interference | Incandescent light source | 3000 Lux | |
Fluorescent light source | 3000 Lux | ||
Solar light source | 10000 Lux | ||
EMC | EMS | It meets the requirements of GB/T19436-1 and GB4584-2007 for four-level security grating. | |
EMI | Meet the requirements of EN61326-1 and EN55011 for electromagnetic radiation of industrial sites. | ||
Anti-vibration ability | Frequency 10Hz~55Hz; Amplitude: 0.35 0.05mm; Scanning times: three axes, 20 times per axis. | ||
Impact resistance | Acceleration 10g; Pulse duration: 16 ms; Collision times: three axes, each axis is 1000 10 times. | ||
the protection grades | IP65 | ||
outline dimension | 52×36×Jmm (J is the length of transmitter/receiver) | ||
Electrical characteristics | |||
Power supply voltage | DC24V±10% | ||
Consumption current | launcher | ≤300mA | |
receiver | ≤1OOmA (無(wú)負(fù)載） | ||
Response time | ＜18ms | ||
Output characteristics | NPN output | The output X2 of NPN transistor (ON when the light is turned on), the load current is less than 300mA, and the residual voltage is less than 3V (excluding the influence of wire extension). | |
PNP output | The output X2 of PNP transistor (ON when the light is turned on), the load current is less than 300mA, and the residual voltage is less than 3V (excluding the influence of the lead delay PNP output length). | ||
sensor | 4 group | Ordinary photoelectric sensor | |
