LA4 safety light curtain

▊	Safety light curtain selection table

		Security level 4 hand	Security level 4 hand	Security level 4 Material inlet and outlet

select type mark accurate	model	LA4	LC4	LS4A
	security level/phase	Security level 4 GB/T 19436 IEC 61496	Security level 4 GB/T 19436 IEC 61496	Security level 4 GB/T 19436 IEC 61496
	Security category	Type 4 Cat.4 PLe	Type 4 Cat.4 PLe	Type 4 Cat.4 PLe
	DCavg	99%	99%	99%
	CCF	100	100	100
	MTTFd	≧40year	≧40year	≧40year
	effective range	0.5-6 Meters (default) Selectable type	0-6rice	0.5-6rice
	Protective height	245-1500mm	140-1420mm	245-1500mm
	resolution ratio	25mm/45mm	15mm/26mm	25mm/45mm
	Beam spacing	20mm/40mm	10mm/20mm	20mm/40mm
	Response time	<18ms	<18ms	<18ms
Power Supply		24VDC	24V DC	24VDC
in-out	Safe output	2個(gè)PNPoutput	2個(gè)PNPoutput	2個(gè)PNPoutput
in-out	Reset input	Manual/automatic	Manual/automatic	Manual/automatic

▊	Reminders of safety light curtain selection

·To protect the upper limbs, the resolution of 25mm should be selected (please pay attention to calculating the safe distance).

·Please use a resolution of more than 38mm to protect the whole body from entering (please pay attention to calculating the safe distance).

▊	LA4 safety light curtain


Level 4 safety light curtain

·Can protect fingers, palms, arms and other upper and lower limb detection.

·25 resolution protection height from 140mm to 1420mm.

·38 resolution protection height from 150mm to 2130 mm.

·Maximum protection distance is 12m.

·Integrated manual or automatic reset

·External relay feedback input (EDM)

·25 resolution, customizable, adding floating and fixed shielding functions.

▊	Specifications, models, optical axis spacing, 20mm resolution

safety monceesafety monceesafety moncee

name	model	resolution ratio	Effective protection height	MTTFD (year)	PFHD (1/h)	MTTF（year）	Download product digital model (right-click link to save as)
safety moncee	LA4-20-0240	25	140mm	358	6.44E-09	65	LA4-20-0240.stp
safety moncee	LA4-20-0280	25	180mm	345	7.04E-09	63	LA4-20-0280.stp
safety moncee	LA4-20-0300	25	220mm	332	7.04E-09	62	LA4-20-0300.stp
safety moncee	LA4-20-0360	25	260mm	321	7.04E-09	60	LA4-20-0360.stp
safety moncee	LA4-20-0400	25	300mm	311	7.76E-09	59	LA4-20-0400.st p
safety moncee	LA4-20-0440	25	340mm	301	7.76E-09	57	LA4-20-0440.stp
safety moncee	LA4-20-0480	25	380mm	292	7.76E-09	56	LA4-20-0480.stp
safety moncee	LA4-20-0500	25	420mm	283	8.67E-09	55	LA4-20-0500.st p
safety moncee	LA4-20-0560	25	460mm	275	8.67E-09	54	LA4-20-0560.stp
safety moncee	LA4-20-0600	25	500mm	267	8.67E-09	53	LA4-20-0600.st p
safety moncee	LA4-20-0640	25	540mm	260	8.67E-09	52	LA4-20-0640.stp
safety moncee	LA4-20-0680	25	580mm	253	9.81E-09	50	LA4-20-0680.stp
safety moncee	LA4-20-0700	25	620mm	246	9.81E-09	49	LA4-20-0700.st p
safety moncee	LA4-20-0760	25	660mm	240	9.81E-09	49	LA4-20-0760.stp
safety moncee	LA4-20-0800	25	700mm	234	9.81E-09	48	LA4-20-0800.st p
safety moncee	LA4-20-0840	25	740mm	228	1.08E-08	47	LA4-20-0840.stp
safety moncee	LA4-20-0880	25	780mm	223	1.08E-08	46	LA4-20-0880.stp
safety moncee	LA4-20-0900	25	820mm	218	1.08E-08	45	LA4-20-0900.st p
safety moncee	LA4-20-0960	25	860mm	213	1.08E-08	44	LA4-20-0960.stp
safety moncee	LA4-20-1000	25	900mm	208	1.19E-08	43	LA4-20-1000.st p
safety moncee	LA4-20-1040	25	940mm	204	1.19E-08	43	LA4-20-1040.stp
safety moncee	LA4-20-1080	25	980mm	199	1.19E-08	42	LA4-20-1080.stp
safety moncee	LA4-20-1100	25	1020mm	195	1.19E-08	41	LA4-20-1100.st p
safety moncee	LA4-20-1160	25	1060mm	191	1.19E-08	41	LA4-20-1160.stp
safety moncee	LA4-20-1200	25	1100mm	188	1.33E-08	40	LA4-20-1200.stp
safety moncee	LA4-20-1240	25	1140mm	184	1.33E-08	39	LA4-20-1240.stp
safety moncee	LA4-20-1280	25	1180mm	180	1.33E-08	39	LA4-20-1280.stp
safety moncee	LA4-20-1300	25	1220mm	177	1.33E-08	38	LA4-20-1300.st p
safety moncee	LA4-20-1360	25	1260mm	174	1.33E-08	38	LA4-20-1360.stp
safety moncee	LA4-20-1400	25	1300mm	171	1.33E-08	37	LA4-20-1400.st p
safety moncee	LA4-20-1440	25	1340mm	168	1.50E-08	36	LA4-20-1440.stp
safety moncee	LA4-20-1480	25	1380mm	165	1.50E-08	36	LA4-20-1480.stp
safety moncee	LA4-20-1500	25	1420mm	162	1.50E-08	36	LA4-20-1500.st p
explain	The detection distance of the models listed in the table defaults to Type A: 0~ 6m, and other detection distances are selected as follows.:LA4-20-口口口口(height)-口(B、D、E):among，Btype:0~12m，Dtype:0~20m;Etype:0~40m;Etype:0~30m;

▊	Specifications, models, optical axis spacing, 30mm resolution

safety monceesafety monceesafety monceesafety monceesafety monceesafety monceesafety monceesafety moncee

name	model	resolution ratio	Effective protection height	MTTFD(year)	PFHD(1/h)	MTTF（year）
safety moncee	LA4-30-030	38	150mm	372	6.44E-09	67
safety moncee	LA4-30-0240	38	210mm	358	6.44E-09	65
safety moncee	LA4-30-0360	38	270mm	345	7.04E-09	63
safety moncee	LA4-30-0420	38	330mm	333	7.04E-09	62
safety moncee	LA4-30-0480	38	390mm	321	7.04E-09	60
safety moncee	LA4-30-0540	38	450mm	311	7.76E-09	59
safety moncee	LA4-30-0600	38	510mm	301	7.76E-09	57
safety moncee	LA4-30-0660	38	570mm	292	7.76E-09	56
safety moncee	LA4-30-0720	38	630mm	283	8.67E-09	55
safety moncee	LA4-30-0780	38	690mm	275	8.67E-09	54
safety moncee	LA4-30-0840	38	750mm	267	8.67E-09	53
safety moncee	LA4-30-0900	38	810mm	260	8.67E-09	52
safety moncee	LA4-30-0960	38	870mm	253	9.81E-09	50
safety moncee	LA4-30-1020	38	930mm	246	9.81E-09	49
safety moncee	LA4-30-1080	38	990mm	240	9.81E-09	49
safety moncee	LA4-30-1140	38	1050mm	234	9.81E-09	48
safety moncee	LA4-30-1200	38	1110mm	228	1.08E-08	47
safety moncee	LA4-30-1260	38	1170mm	223	1.08E-08	46
safety moncee	LA4-30-1320	38	1230mm	218	1.08E-08	45
safety moncee	LA4-30-1380	38	1290mm	213	1.08E-08	44
safety moncee	LA4-30-1440	38	1350mm	208	1.19E-08	43
safety moncee	LA4-30-1500	38	1410mm	204	1.19E-08	43
safety moncee	LA4-30-1560	38	1470mm	199	1.19E-08	42
safety moncee	LA4-30-1620	38	1530mm	195	1.19E-08	41
safety moncee	LA4-30-1680	38	1590mm	191	1.19E-08	41
safety moncee	LA4-30-1740	38	1650mm	188	1.33E-08	40
safety moncee	LA4-30-1800	38	1710mm	184	1.33E-08	39
safety moncee	LA4-30-1860	38	1770mm	180	1.33E-08	39
safety moncee	LA4-30-1920	38	1830mm	177	1.33E-08	38
safety moncee	LA4-30-1980	38	1890mm	174	1.33E-08	38
safety moncee	LA4-30-2040	38	1950mm	171	1.33E-08	37
safety moncee	LA4-30-2100	38	2010mm	168	1.50E-08	36
safety moncee	LA4-30-2160	38	2070mm	165	1.50E-08	36
safety moncee	LA4-30-2220	38	2130mm	162	1.50E-08	35
explain	The detection distance of the models listed in the table defaults to Type A: 0~6m, and other detection distances are selected as follows.:LA4-30-口口口口(height)口(B、D、E);among，Btype:0~12m，Dtype:0~20m;Etype:0~40m;Etype:0~30m;

▊	technical parameter

executive standard	GB/T 19436.1;GB/T 19436.2;GB 4583-2007;IEC 61496-1;IEC 61496-2
Security category
security level/phase		Type 4 Cat.4 ple
DCavg		99%
CCF		100
MTTFD/PFHD		(See the specification sheet of safety grating in the detailed manual)
Optical characteristics
Detection light source		Infrared LED (center wavelength 940mm)
Detection height		Optical axis spacing x (number of beams -1)
EAA		Meet the requirements of IEC61496-2. When the detection distance is more than 3m, EAA is less than 2.5.
Environmental characteristics
ambient temperature	work		-10℃~55℃（No frosting and fog condensation）
	store		-40℃~70℃
ambient humidity	work		36%RH~85%RH
	store		36%RH~95%RH
Anti-light interference	Incandescent light source		3000 Lux
	Fluorescent light source		3000 Lux
	Solar light source		10000 Lux
EMC	EMS		Meet the requirements of GB/Tl9436-l and GB4584-2007 for four-level security grating.
	EMI		Meet the requirements of EN61326-l and EN55011 for electromagnetic radiation of industrial sites.
Anti-vibration ability			Frequency 10Hz~55Hz; Amplitude: 0.35 0.05mm; Scanning times: three axes, 20 times per axis.
Impact resistance			Acceleration 10g; Pulse duration: 16 ms; Collision times: three axes, each axis is 1000 10 times.
the protection grades			IP65
outline dimension			52ⅹ36ⅹJmm (j is the transmitter/receiver length)
Electrical characteristics
Power supply voltage			DC24V±10%
Consumption current	launcher		≤(300mA）
	receiver		≤lOOmA (non-loaded）
Response time			＜18ms
Output characteristics	PNP output		The output X2 of NPN transistor (ON when the light is turned on), the load current is less than 300mA, and the residual voltage is less than 3V (excluding the influence of wire extension).
	PNP output		The output X2 of PNP transistor (ON when the light is turned on), the load current is less than 300mA, and the residual voltage is less than 3V (excluding the influence of the lead delay PNP output length).

▊	safety control

·Dual channel safety loop input

·A variety of configurable safety control modules, supporting a variety of safety component inputs.

·Multi-channel safe output, meeting the output category standard.

·Configuration software can be used to set safety control logic to meet various field application requirements.

·security certificate：PLe

SR103

SM302

SM602

product name	model	Safety input	output
safety relay	SR103系列	1Group security product	3NO+1NC
Safety controller	SM302系列	3Group security product	2NO
Safety controller	SM602系列	6Group security product	2NO+4SO
explain	Input product Emergency stop button, safety door lock, two-hand button, safety grating, safety pad, reset, etc.
